Roof tile pitch specifications are one of the most challenging aspects in UK roofing projects. Architects face the challenge of balancing design ambition with the technical constraints of minimum pitch thresholds, while main contractors must manage the risk of non-compliant specifications that can lead to water ingress, failed inspections, and costly remedial work.

When pitch, headlap, and fixing requirements are not correctly aligned from the outset, the consequences affect project timelines, budgets, and the long-term performance of the building envelope.

At FP McCann, our technical team works with architects, main contractors and sub-contractors across the UK to ensure that pitch specifications are accurate, compliant with BS EN 490, and aligned with both the design intent and practical site requirements.

Whether you are specifying tiles at the design stage or confirming fixing details ahead of installation, we provide the guidance and product range to support your project from start to finish.

Using our online Fixing Specification tool, you can generate detailed fixing schedules based on your specific project parameters, including roof pitch, location, and exposure zone.

GET IN TOUCH

Head Office

3 Drumard Road ,Knockloughrim, Magherafelt, BT45 8QA

028 7964 2558    sales@fpmccann.co.uk

TECHNICAL DOWNLOADS

FP MCCANN CONCRETE ROOF TILE RANGE – PITCH SPECIFICATIONS AT A GLANCE

FP McCann manufactures a comprehensive range of concrete roof tiles, each with defined pitch specifications. The table below provides a summary of our key products and their minimum pitch requirements.

For full technical data sheets and colour options for each product, visit our Concrete Roof Tile product page.

LOW PITCH ROOFING SOLUTIONS

Low pitch roofs present unique challenges. Many standard tiles are not suitable below 17.5°, and incorrect specification can result in water pooling, wind-driven rain ingress, and tile failure.

FP McCann’s Centurion Low Pitch Concrete Roof Tile is specifically designed for roofs with pitches as low as 10°. This makes it an ideal choice for architects working on contemporary designs, extensions, and commercial buildings where shallow roof angles are required.

The Centurion tile features hidden fixings and certified quality, providing a clean aesthetic while delivering reliable weatherproofing performance at very low pitches.

For pitches between 17.5° and 22.5°, tiles such as the Thin Flat and Duo Thin Flat provide a sleek, slate-like appearance with excellent performance when specified at the correct headlap.

TECHNICAL FACTORS THAT AFFECT PITCH SPECIFICATION

Pitch specification does not exist in isolation. Several interrelated technical factors must be considered together to ensure a compliant and effective roofing installation.

HEADLAP AND BATTEN GAUGE

The headlap is the amount of vertical overlap between courses of tiles. Increasing the headlap improves weathertightness and allows tiles to be used at lower pitches, but it also reduces the batten gauge and increases the number of tiles required per square metre. For example, a Thin Flat tile at 75mm headlap covers approximately 9.7 tiles per m², while at 100mm headlap coverage increases to approximately 10.5 tiles per m².

FIXING REQUIREMENTS

The method and frequency of tile fixing depends on roof pitch, wind load zone, and the specific tile profile. Lower pitch installations and exposed locations typically require more fixings per tile. FP McCann provides guidance on nail sizes, clip types, and fixing patterns for every tile in our range.

Our online Fixing Specification tool allows specifiers to input project-specific parameters and generate a tailored fixing schedule, ensuring full compliance with BS 5534 and BS EN 490.

WIND EXPOSURE AND GEOGRAPHIC LOCATION

The UK is divided into wind exposure zones that influence fixing requirements. Tiles on roofs in exposed coastal or elevated locations may require additional fixings compared to sheltered inland sites, even at the same pitch. FP McCann’s technical team can advise on exposure zone calculations and help ensure fixing schedules are appropriate for the project location.

SPECIFICATION SUPPORT FOR ARCHITECTS

Architects need materials that deliver both design flexibility and regulatory compliance. FP McCann supports architects with CAD details and BIM objects, minimum pitch and fixing data for every tile in our range, colour matching guidance across a wide palette of finishes, and technical advice on roof geometry, ventilation, and drainage performance.

Our in-house design team is available to work with architects from the early design stage, ensuring that tile choices align with planning requirements and the overall design intent. By engaging early, architects can avoid costly specification changes later in the programme.

RELIABLE SERVICE FOR MAIN CONTRACTORS

For main contractors, reliability and programme certainty are essential. FP McCann supports main contractors with accurate and prompt quotations from our estimating team, coordinated deliveries aligned with the site programme, high production capacity to meet tight deadlines, and consistent product quality from our controlled manufacturing process.

Our precast manufacturing process ensures consistent dimensions and finishes across every batch, reducing the risk of on-site issues and rework that can slow down the roofing element of the build.

INSTALLATION BENEFITS FOR SUB-CONTRACTORS

Roofing sub-contractors value consistency, speed, and clear technical guidance. FP McCann tiles are designed with uniform sizing for efficient laying, and our products are packed and delivered with care to minimise breakage and wastage on site.

Our Multi Ridge Roof Tile streamlines complex ridge detailing, and our Hip End Tile provides a neat finish at hip junctions.

We also provide guidance on common installation considerations such as efflorescence, helping sub-contractors identify and manage this natural process before it becomes a concern.

All cutting and handling of concrete roof tiles should be carried out in accordance with HSE Roof Tile Guidance, which provides advice on controlling dust exposure during tile cutting operations on site.

CASE STUDY: THIN FLAT DUO TILES AT MANCHESTER CARE FACILITY

FP McCann recently supplied Anthracite Thin Flat Duo Concrete Roof Tiles and Ridge Tiles to a new 59-bed care facility in Northern Moor, Wythenshawe, Manchester. The project, developed by Lovett Care Ltd and Liberty Care Developments, required a roofing solution that would provide a distinctive, modern contrast to the brick finish of the three-storey building.

Specialist commercial roofing company D&D Roofing Ltd installed approximately 10,000 tiles, with the Thin Flat Duo’s consistent sizing and interlocking profile enabling efficient installation across the complex roof geometry of the care home.

Read the full case study: FP McCann Thin Flat Duo Roof Tiles Installed on Manchester Care Facility

SUSTAINABILITY AND COMPLIANCE

FP McCann’s concrete roofing tiles are manufactured using environmentally responsible processes. Our newest manufacturing facility in Cadeby, Leicestershire, uses solar panels to provide 100% of the plant’s energy requirement, demonstrating our commitment to leading the drive for net zero carbon emissions as part of the UK Government’s Net Zero Strategy.

All tiles are produced to meet or exceed BS EN 490 standards, and we can provide Environmental Product Declarations (EPDs) and full technical documentation to support specification and compliance with BREEAM or sustainability-led project requirements.

USE OUR ONLINE FIXING SPECIFICATION TOOL

FP McCann’s online Fixing Specification tool allows architects, contractors and sub-contractors to generate project-specific fixing schedules quickly and accurately. By inputting details such as tile type, roof pitch, headlap, exposure zone, and rafter spacing, the tool produces a compliant fixing specification that can be used directly in project documentation.

This resource is designed to save time during the specification process and ensure that fixing requirements are tailored to the precise conditions of each project.

WHY CHOOSE FP MCCANN FOR YOUR ROOF TILE SPECIFICATION?

With over 45 years of experience in precast concrete manufacturing and 14 ISO-accredited facilities across the UK, FP McCann is a trusted partner for construction professionals who need dependable roofing solutions backed by expert technical support.

As a family-run business, we take pride in the relationships we build with our customers. Our team provides honest advice, responsive service, and a genuine commitment to helping your project succeed.

What sets us apart: a comprehensive concrete roof tile range covering pitches from 10° upwards; trusted service across sales, design, manufacture, delivery and installation; strong communication and dedicated technical support; and a national reputation backed by local family values.

CONTACT FP MCCANN FOR ROOF TILE PITCH SPECIFICATION SUPPORT

Whether you are at the design, procurement, or construction stage, FP McCann is ready to support your next roofing project with expert guidance on pitch specifications and a dependable range of concrete roof tiles.

Visit our Concrete Roof Tile product page for technical specifications, BIM objects, and downloadable datasheets.
