The precast L Wall units are ideal for forming both retaining and containing structures in residential, commercial, industrial and waste developments.

Key Features of L Shaped Concrete Retaining Walls

L Wall units are an ideal product where the speed of installation is necessary. They offer a fast, cost-effective solution for constructing retaining and containing developments. Standard sizes range from 1m high up to 3.75m high with a width of 1m or 2m depending on height dimensions. We now also offer L Walls in heights of 4m-6m.

Also, L-Wall units can be combined with either prestressed concrete panels or Rocket Walls™ to form storage facilities:

  • Create storage bays without imposing a load to the building frame
  • Can be loaded either side or both sides of the stem
  • Available with heel feature to reverse (NI only)
  • No heel-sheer reverse face (GB only)
  • Retain material up to 19kN/m³ and AoR 20° or an additional 10kN/m³
  • Large range of sizes available
  • No specialist trades required
  • Quick and easy installation
  • Corner units available for the 1m widths
  • Stability

The precast concrete L wall units are ideal for forming both retaining and containing structures in residential, commercial, industrial and waste developments

  • Making up levels within buildings
  • Landscaping of housing estates
  • General soil retention
  • Waste recycling bunkers
  • Load one side or both
  • Corner units available
  • General soil retention
  • Retaining walls
  • Fast installation
  • Division Walls
  • Bunker Walls
  • Bulk Storage

STANDARD SIZES

Designed for retained material with a density of 18 kN/m³
(Approximate bulk density of 1800 kg/m³)

StandardSizes_LWalls

(Include 5% lifting allowance)

ANCHORS FOR STANDARD CONDITIONS

AnchorRequirements_LWalls

Foundation

The foundation requirements should be determined by a qualified engineer. Units placed on a concrete foundation should be bedded on a mortar and wedged to attain correct alignment. FP McCann recommends that L wall units are suitably anchored to the foundation.

NEW 4m-6m L Wall

FP-McCann-new-4-6m-L-Walls-Dimensions-Table
FPMcCann-Walling-Lwalls-Render

NEW Brick Slips for L Wall Units

FPMcCann-Precast-Walling-Brick-Slip-L-Walls-Swatches
